Static Voltage Stabilizer in Kerala Cochin – stable and consistent power supply is essential for the smooth functioning of any industrial, commercial or even residential setup. In Kerala and Cochin, a static voltage stabilizer is an indispensable solution to regulate the voltage and improve the power quality in these setups.
“The Importance of a Static Voltage Stabilizer in Protecting Equipment in Kerala and Cochin
By using a static voltage stabilizer, you can maximize the life of your equipment and protect it from the harmful effects of voltage fluctuations. Additionally, these devices ensure a stable power supply, which is essential for the smooth functioning of sensitive equipment. Choose the right static voltage stabilizer based on your power needs and the type of equipment you use, and enjoy the peace of mind that comes with a safe and stable power supply. Static Voltage Stabilizer in Kerala Cochin
| Description | Static Stabilizer | Servo Stabilizer |
|---|---|---|
| Input Voltage | Customized as per requirement | Customized as per requirement |
| Output Voltage | Air Cooled | Cooling |
| Rate of Correction | 4,000 v/sec. | 70 v/sec. |
| Response Time | 50 micro sec. | 10 mili sec. |
| Max Efficiency | >98% | 90-95% |
| Standard specification | Standard specification- customization is expensive | Standard specification-customization is expensive |
| Cooling Type | Air cooled | Oil cooled/air coole |
| Short Time Overload | 400% for 500 msec. | 200% for 2 sec. |
| Effect of Spikes & Surges | Spikes/surges are likely to be generated or transmitted to output. | No spikes/surges are either generated or transmitted to output. |
| Effect of fluctuation | No voltage fluctuations are transmitted to output as response time is fast & no mechanical switching. | Fluctuations may be transmitted to O/P due to mechanical switching. |
| Maintenance | No moving part and hence no maintenance. | Considerable maintenance of servo motor & other moving parts required. |
| Insulation | Class-H insulation (works upto 175 deg.) | Insulation with lower class – cannot handle high inner temperature inside cabinet. |
| Control Circuit | High Frequency PWM controlled IGBT. | Low frequency operation – Solid State sensing & feedback through control circuit to operate electromagnetic relays for operating motors. |
| Size per watt | Small foot print & very compact. | Large Size. Static Voltage Stabilizer in Kerala Cochin |
| Protections | Over load, over voltage, under voltage, single phase out, phase reversal, phase unbalance, thermal protection etc. | Technology constraints – some of the protections are not possible. |
